18-in-1 USB C Docking Dtation

In stock
$179.00
$179.00

Upgraded 18-in-1 Quadruple Display Docking Station with SSD Enclosure

3 *4KHDMI, DP, 3*USB3.0, 2 *USB 2.0, 100W PD 3.0 for laptop charging, SD/TF Card Slot,1 RJ45, 3.5mm audio jack, 2*USB-C to Host.Plug-play and easy operation. Sturdy full aluminum unique heat disspation design. An ideal device covering all the features you need. Mac OS users will simply connect HOST1 + HOST2 ports to your laptop.

Plug & Play installation requires no drivers and allows you to easily connect additional storage to your PC, Laptop, Gaming Console, Router, etc. for quick data transfers or media sharing.

    M.2 SATA SSD Enclosure

    Supports B&M Key and B Key NGFF SSD with a maximum capacity of 2TB.

    Support Format: Windows:NTFS/FAT32/exFAT, Mac OS:HFS+/ex FAT

    Support Capacity:Support 2 TB at Max

    Plug & Play installation requires no drivers and allows you to easily connect additional storage to your PC, Laptop, Gaming Console, Router, etc. for quick data transfers or media sharing.

    Note: SSD is not included.

    Quadruple Display

    HOST 1 Drive HDMI1(4k@60Hz),

    HOST 2 Drivers VGA(1080P@60Hz), HDMI2(4k@60Hz), HDMI3(4k@30Hz).

    Support MST Triple Display for Mac OS & Quadruple Display for Windows

    Once VGA is connected, all monitors connected to HOST2 will be limited to 1920x1080@60Hz max.

    Expand Your Capabilities

    3 USB 3.0 + 1 USB-C ports provide fast 5 Gbps data transfer rates. Ideal for external hard drives, thumb drives, printers, scanners, tablets, or smartphones.

    2 USB 2.0 ports provide a 480Mbps max transfer rate and are perfect for adding peripherals, such as a wireless mouse or keyboard (with no signal interference).



    Fast Power Delivery

    Supports up to 100W max power to charge your devices and significantly shorten charging time.

    It will fully charge a Mac Pro 13” in under 2 hours!

    Before you purchase, please confirm your source device own the USB-C port which supports DP Alt Mode:

    1. USB-C 3.1 Gen 1: 5Gbps bandwidth, only several models like Macbook 2015 could support Display

    2. USB-C 3.1 Gen 2: 10Gbps bandwidth, supports one or two Displays

    3. USB 3.2: 20Gbps bandwidth, support three Displays

    4. Thunderbolt 3/4: 40Gbps bandwidth, support quadruple Displays.(With two HOSTs)

    # Half-Speed Thunderbolt 3: 20Gbps bandwidth only, support three Displays.

    On Mac devices:CAN NOT support MST Display, ONLY Mirror Mode due to Mac OS limitation; Not support Macbook pro air mini M1

    4K Resolution:The final resolution of HDMI output depends on your host devices. (ONLY when your devices support 4K resolution, the video output will be 4K).

    Compatible:This USB C Docking Station ONLY work with those devices that the USB Type C Port supports video output or DP Alt Mode. , please check if your laptop owns a USB Type-c Thunderbolt 3 port and support DisplayPort Alternate Mode.

    Can NOT work with (Tested):HP EliteBook 745 G4 / HP Elitebook 820 G3 / HP EliteBook 828 G4 / HP 14s-be102TX / HP 14-ce1004TX 14 / HP Probook 650 G2 / HP Probook 455 G4 / HP Probook 430 G5 / HP Pavilion-14 bf116tx / HP Pavilion 15 ck009 / HP Pavilion Power Laptop 15-cb / Lenovo ideapad 340s Tablets / Google Pixel phones / Nintendo Switch / Acer Aspire A5 / Oneplus 5T Phone

    May blackout for a few seconds(Extended Display Identification Data) may blackout for a few seconds(1 minute at max, depends on Laptop and monitor) when data transfer; Please be patient wait for the data completed.

    Charge laptop:Please plug in the Laptop's power adapter before connecting multiple display purpose.

    Upgraded 18-in-1 Quadruple Display Docking Station with SSD Enclosure

    3 *4KHDMI, DP, 3*USB3.0, 2 *USB 2.0, 100W PD 3.0 for laptop charging, SD/TF Card Slot,1 RJ45, 3.5mm audio jack, 2*USB-C to Host.Plug-play and easy operation. Sturdy full aluminum unique heat disspation design. An ideal device covering all the features you need. Mac OS users will simply connect HOST1 + HOST2 ports to your laptop.

    Plug & Play installation requires no drivers and allows you to easily connect additional storage to your PC, Laptop, Gaming Console, Router, etc. for quick data transfers or media sharing.



    Multiple Display USB C Docking Station Compatibility List:

    Full compatible with these devices(Both Data Transfer And Charge, Not a full list)

    1) Macbook 2015/ 2016/2017/2018/2019

    2) Macbook Pro13"/15" 2016/2017/2018/2019

    3) Google Chromebook 2016/2017/2018

    4) Microsoft Lumia 950/950XL

    5) Huawei Matebook 2016/2017/2018. An extra 60W power plug needed for power delivery to work.

    6) Dell XPS13/15. An extra 60W power plug needed for power delivery to work.

    7) Dell Latitude Series/Vostro Series/Precision Series/nspiron series

    8) HP Spectre Notebook/EliteBook Series/Pro Series/Zbook Series

    9) Acer Aspire R13/V15 Nitro/V17 Nitro

    10) Asus Zenbook Pro UX Series

    11) Asus Ling Yao 3, Ling Yao 3 PRO, Ling Yao X Series

    12) Lenovo ThinkPad 25/P Series/T Series/X Series

    13) Lenovo IdeaPad 500/700/900 Series

    Make sure the type c power delivery port on your laptop supports the DisplayPort Alt Mode and the type C port is USB 3.1 Type-C (Gen2) or Thunderbolt 3 port.Note: Some Thunderbolt 3 ports just work as the half-speed TB3 port(20Gbps Max),which means you will not get enough bandwidth to support all your monitors and other devices.

    Note:


    1. Mac OS and Chrome OS do not support Extended mode. Additional monitors can only mirror the source screen instead of extending your desktop to three separate screens under No-Mirror mode. Once the VGA port is connected, the resolution of all monitors connected to the HOST2 port will be limited to 1920 x 1080@60Hz (maximum)

    2. UtechSmart M.2 SSD Enclosure can support only M.2 B-KEY or B&M-Key SATA SSDs, it does not support M.2 PCIe AHCI SSDs nor any SSD from Mac.

    Speed will vary depending on your computer's and SSD's performance.

    3.It is normal for the case to heat up, as high-speed M.2 drives generate heat while working.

    Please avoid touching the SSD while in use

    4. The source Laptop's power adapter must first be plugged into

    the USB-C Power Delivery port before connecting an external hard drive or multiple

    devices to the Docking Station. If your laptop utilizes an AC adapter,

    please use the OEM adapter to charge, as it will provide the fastest charging speed. HP and Dell do not allow 3rd party chargers to charge their equipment.

    5. Due to the process of EDID (Extended Display Identification Data) communication

    your displays may cause your displays to blackout for a few seconds once plugged in.

    They should recover shortly, but speed depends on the source device and monitor (1 minute at max).

    6. HDMI signal cannot be transferred to DP signal; DP monitors are not supported.
